RESPONSIBLE FOR METADATA BKG (Bundesamt fuer Kartographie und Geodaesie)
RESPONSIBLE AGENCY BKG (Bundesamt fuer Kartographie und Geodaesie)
CURRENT STATION CONFIGURATION sofi00bgr_20211005.log
STATUS IN EPN included since 22-06-1997
LAST AVAILABLE DATA 04-10-2022
LAST RECEIVER LEICA GR50 (26-05-2021 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA LEIAR25.R3 LEIT (29-04-2010 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 09160008) from 2010-04-29 to now :
DATA ROUTINELY ANALYSED BY BEK, BEV, BKG, RGA, SGO
INCLUSION IN OTHER NETWORK(S) IGS, EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 10-02-2021.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 037/2021 N/A
BEV 037/2021 N/A
BKGI 037/2021 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 271/2022 78.57%
BEV 277/2022 100%
BKGI 277/2022 100%
Hourly
Data centres Online Last data Availability Latency
BEV 037/2021 (D) N/A 0%
BKGI 037/2021 (C) N/A 0%
Hourly
Data centres Online Last data Availability Latency
BEV 278/2022 (L) 100% 95.24%
BKGI 278/2022 (L) 100% 92.86%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

Real-time

SOFI00BGR0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/05 00:07 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/05 00:07 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2022/10/05 00:07 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

    2022/10/05 00:07 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1315 m) exceeds threshold

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/04 22:24 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/04 22:24 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

    2022/10/04 22:24 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1315 m) exceeds threshold

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2022/10/05 03:30 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt site log (GPS+GLO+GAL+BDS+SBAS)

    2022/10/05 03:30 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (4.50.274) wrt site log (4.50/7.710)

    2022/10/05 03:30 RTCM 3.2/1006: Coordinate difference with ETRS89 ( 0.1315 m) exceeds threshold

information above extracted from monitor files - https://epncb.eu/ftp/station/real_time/

Location

Pictures
