RESPONSIBLE AGENCY LPT (Swiss Federal Office of Topography (swisstopo))
RESPONSIBLE FOR METADATA LPT (Swiss Federal Office of Topography (swisstopo))
CURRENT STATION CONFIGURATION zim200che_20230131.log
STATUS IN EPN included since 16-12-2007
LAST AVAILABLE DATA 07-10-2024
LAST RECEIVER TRIMBLE NETR9 (31-01-2023 to now)
SET TO TRACK GPS+GLO+GAL+BDS
LAST ANTENNA TRM59800.00/NONE (10-10-2013 to now)
INDIVIDUAL CALIBRATION(S)
  • TRM55971.00/NONE (SN: 30318066) from 2007-11-08 to 2009-05-12 :
  • TRM59800.00/NONE (SN: 60369) from 2009-05-12 to 2013-10-10, from 2013-10-10 to now :
DATA ROUTINELY ANALYSED BY BEK, COD, IGE, LPT, RGA, ROB
INCLUSION IN OTHER NETWORK(S) IGS
RINEX V2.11 - GPS+GLO+GAL
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 275/2024 78.57%
BEV 281/2024 100%
BKGI 281/2024 100%
RINEX V3.04 - GPS+GLO+GAL+BDS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 275/2024 78.57%
BEV 281/2024 100%
BKGI 281/2024 100%
Hourly
Data centres Online Last data Availability Latency
BEV 283/2024 (B) 100% 97.62%
BKGI 283/2024 (B) 100% 97.62%
Hourly
Data centres Online Last data Availability Latency
BEV 283/2024 (C) 100% 99.4%
BKGI 283/2024 (C) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

Real-time

ZIM200CHE0 :

  • ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/10/08 00:18 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS) wrt source table (GPS+GLO)

    2024/10/08 00:18 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 5.56 / Boot 5.56) wrt site log (5.56)

  • BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/10/07 01:26 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 5.56 / Boot 5.56) wrt site log (5.56)

    2024/10/07 01:26 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.0000 m) wrt site log (0.08935 m)

  • ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS (MSM5)

    2024/10/08 16:48 RTCM 3.2/1033: Incorrect Receiver Firmware Version in stream (Nav 5.56 / Boot 5.56) wrt site log (5.56)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/
