RESPONSIBLE AGENCY LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
RESPONSIBLE FOR METADATA LMV (Lantmäteriet, the Swedish mapping, cadastral and land registration authority)
CURRENT STATION CONFIGURATION vae600swe_20221206.log
STATUS IN EPN included since 22-06-2014
DATA LICENSE CC-BY-4.0
LAST AVAILABLE DATA 14-10-2024
LAST RECEIVER TRIMBLE ALLOY (05-12-2022 to now)
SET TO TRACK GPS+GLO+GAL+BDS+SBAS
LAST ANTENNA TPSCR.G5/OSOS (16-03-2022 to now)
INDIVIDUAL CALIBRATION(S)
  • LEIAR25.R3/LEIT (SN: 09030007) from 2011-08-25 to 2022-03-16 :
  • TPSCR.G5/OSOS (SN: 76212004) from 2022-03-16 to now :
DATA ROUTINELY ANALYSED BY BEV, BKG, NKG, ROB
INCLUSION IN OTHER NETWORK(S) EPOS

The RINEX 2 data are no more submitted to the EPN data centres since 28-04-2020.

RINEX V2.11 - GPS+GLO
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 118/2020 N/A
BEV 023/2020 N/A
BKGE 118/2020 N/A
RINEX V3.04 - GPS+GLO+GAL+BDS+SBAS
Daily
(data calendar)
Data centres Online Last data Availability Download
EPNCB (historical) 281/2024 75%
BEV 288/2024 100%
BKGE 288/2024 100%
Hourly

No recent data available

Hourly
Data centres Online Last data Availability Latency
BEV 289/2024 (F) 100% 86.9%
BKGE 289/2024 (E) 100% 100%

Daily and Hourly Latency Plots

Recent RINEX file errors detected by BKG data centre: web page

BKG upload settings to other data centres.

Location

Pictures
