EUREF Permanent GNSS Network

Station Configuration

RESPONSIBLE AGENCY	DUT (Delft University of Technology)
RESPONSIBLE FOR METADATA	DUT (Delft University of Technology)
CURRENT STATION CONFIGURATION	wsrt00nld_20231207.log
STATUS IN EPN	included since 20-07-1997
LAST AVAILABLE DATA	15-04-2024
LAST RECEIVER	SEPT POLARX5 (17-04-2023 to now)
SET TO TRACK	GPS+GLO+GAL+BDS+QZSS+IRNSS+SBAS
LAST ANTENNA	LEIAR25.R4/LEIT (07-12-2023 to now)
INDIVIDUAL CALIBRATION(S)	LEIAR25.R4/LEIT (SN: 726840) from 2023-12-07 to now : GEO - ROBOT (freq: G01, G02, G05, R01, R02, E06, E07, E08, C02, C06, date: 2023-08-29) - careful: not used within EPN analysis
DATA ROUTINELY ANALYSED BY	BKG, LPT, MUT, NKG, ROB
INCLUSION IN OTHER NETWORK(S)	IGS, EPOS

Data Provided

The RINEX 2 data are no more submitted to the EPN data centres since 15-04-2020.

No recent data available

Recent RINEX file errors detected by BKG data centre: web page, API (JSON format)

BKG upload settings to other data centres.

WSRT00NLD0 :

ASI (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM7)
2024/04/16 03:29 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/16 03:29 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3754 m) wrt site log (0.53437 m)

BKG (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM7)
2024/04/16 01:52 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/16 01:52 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3754 m) wrt site log (0.53437 m)

ROB (broadcaster, registration) - RTCM 3.2 : GPS+GLO+GAL+BDS+QZSS (MSM7)
2024/04/16 06:47 RTCM 3.2 : Unexpected constellations in stream (GPS+GLO+GAL+BDS+QZSS) wrt site log (GPS+GLO+GAL+BDS+QZSS+SBAS)
2024/04/16 06:47 RTCM 3.2/1006: Incorrect Antenna Height in stream (0.3754 m) wrt site log (0.53437 m)

information above extracted from monitor files - https://epncb.oma.be/pub/station/real_time/

RINEX Data Quality

Daily tracking performances

Monthly snapshots of satellite tracking

Position, Velocity & Time Series

EUREF is providing positions and velocities for the station WSRT00NLD
Last ETRF2000 position valid from 029/2017 to 316/2022 expressed at epoch 001/2010
X = 3828736.139 m	Vx = -0.0012 m/y
Y = 443304.740 m	Vy = -0.0006 m/y
Z = 5064884.516 m	Vz = -0.0007 m/y
